• The range and bearing will now be updated according to the
ship’s movement.
To set the point to a position outside of the current viewing
window :
• move the cursor outside of the window in the desired
direction and the chart will move automatically in that direction.

New route
Click on the New Route icon to create a new route and to plot
waypoints on the chart with the Mouse on the chart with the Mouse.

The waypoints can be plotted on the chart with the mouse or entered by
keyboard in the route plan window which is activated by clicking the
button Route Plan just after the New Route tool has be selected.

Route plan
Click on the Active Route plan button to display the Route planning
window of the active route.
Remarks
The button is enabled when the Route tool has been selected. Then, if
the route is plotted graphically the button is disabled.
The button is disabled when no active route has been activated.

New log book record
To enter a new record in the log book click on the New Logbook record
icon.

Logbook
Click on the Log Book Window button to display the logbook window
and list the entries of the active logbook.
It will now be possible to change the settings, print the logbook, load an
historical book and replay it.

Set target
To plot a manual target click on the Set target icon.
