Man over board
In the case of a man over board (MOB) click on the icon
A MOB waypoint will be created, showing the time the incint
de was originated.
• The chart will be automatically centred on the MOB point
• A new entry will be stored in the logbook with the MOB
position and navigation parameters
• The current route, if any will be deactivated
• The autopilot function will be cancelled.
• AIS message is broadcasted.

A route defined by a waypoint and plotted from the MOB
point will be created and the information required to return to
the MOB point (bearing and distance from the ship to the
MOB point) will be immediately displayed in the static
information console.

To view and amend the properties of the waypoint, locate the cursor on
the waypoint, click right and select Properties from the pop-up menu.

Deactivate MOB
Locate the cursor on the MOB waypoint and click right. Select Deactivate
on the pop-up menu.

Delete MOB
Locate the cursor on the MOB waypoint and click right. Select Delete on
the pop-up menu.

Event
To plot a new point on the chart at the ships location, click on the Event
icon. The geographical point is displayed on the chart with a special icon
and stored in the user data active layer.
A detailed overview of user data can be found under Object Editor.

Zoom
Click on the Zoom in icon to zoom in one step Hot Key Press Hot Key F1
to zoom in., Press Hot Key F2 to zoom out
IMPORTANT
