In RCDS mode (Raster charts) clicking with the right button of the mouse
in the zoom in button will load and display another raster chart with a
better scale under if it exists
Other methods of zooming can be found in Charts - Zooming

Standard Display
Click on the icon to set the ENC or C-MAP display to standard
mode.
Click on the icon to display ARCS or BSB chart at the original
scale.
Right click on the icon to select Extended Standard and Paper
like presentation

Select area The ‘Select area’ function allows the user to pre-define chart
areas and to select an area to be displayed.
To select and area click on the Select area icon.
A chart area is defined by:
• Name
• Lat (latitude)
• Lon (longitude)
• Scale

Auto centering
Click on the Auto centering icon to define a ‘centering zone’.
When the chart auto-scrolling mode is selected (Follow Ship Checked
ON), the chart will automatically move when the ship moves out of the
‘centering zone’ currently defined.
The navigator can use two kinds of centering zones: static or dynamic
according to the ship’s heading.

Centre on ship
To center the chart about the ship click on the Centre on ship
icon. The chart will automatically be centered about the ship..
NOTE: Centre on ship is a single one-time action.
In order for the chart to scroll automatically, according to the ship’s
movements:
• Click right anywhere on the chart to display the pop-up menu.
• Click on Follow the ship
